• LCD Touch screen and buttons, easy operation

• Compatible with lithium-ion battery and lead acid battery
• Web browser and mobile App monitoring supported
• Improve self-consumption ratio up to 80%, reducing your electricity bill
• DC/AC ratio up to 1.3, completely suitable for double-side PV modular
• Two MPPT design, Max. efficiency of 97.6%
• Programmable charging and discharging schedule
• Both wind turbines and solar panels can be connected as DC input power

Higher yields
- Improve self-consumption ratio up to 80%, reducing your electricity bill
- DC/AC ratio up to 1.3, completely suitable for double-side PV modular
- Two MPPT design, Max. efficiency of 97.6%

User-friendly
- LCD Touch screen and buttons, easy operation
- Compatible with lithium-ion battery and lead acid battery
- Web browser and mobile App monitoring supported

Reliable
- PV lighting protection, Anti-islanding protection, Leakage current protection etc
- Support store energy from DG when needed, ensure the system working within 7*24H
- IP65 protection degree, adapt to indoor and outdoor using
- Automatically switch from on-grid to off-grid mode within 5ms
- Zero exporting function, fast reaction within 200ms in zero export mode

Smart
- Programmable charging and discharging schedule
- Both wind turbines and solar panels can be connected as DC input power
- Max. 16 units can be paralleled for higher system power
- Retrofitting of existing solar system to energy storage system

Battery Input Data
- Battery Type: Lead-acid or Li-lon
- Battery Voltage Range (V): 40-60V
- Max. Charging Current (A): 120A
- Max. Discharging Current (A): 120A
- Charging curve: 3 Stages/Equalization
- External Temperature Sensor: Optional
- Charging Strategy for Lithium Battery: Self-adaption to BMS

PV String Input Data
- Max. DC Input Power (W): 6500W.
- PV input Voltage (V): 370V (100V-500V)
- MPPT Range (V): 125-425V.
- Start-up Voltage (V): 150V.
- PV Input Current (A): 11A 11A.
- No. of MPPT Trackers: 2
- No. of Strings Per MPPT Tracker: 1 1.

AC Output Data
- Rated AC Output and UPS Power (W): 5000W
- Max AC Output Power (W): 5500W
- Peak Power(off-grid): 2 times of rated power, 10 S
- AC Output Rated Current(A): 21.7.4A
- Max.AC Current(A): 25A
- Max Continuous AC Pass-through(A): 35A.
 -Output Frequency and Voltage: 50Hz; 240Vac,
- Grid Type: THD<3%(Linear load<1.5%)
- Current Harmonic Distortion: THD<3% (Linear load<1.5%)

Efficiency
- Max. Efficiency: 97.60%
- Euro Efficiency: 96.50%
- MPPT Efficiency: 99.90%

Protection
- PV Arc Fault Detection: Integrated (Except European Type)
- PV Input Lightning Protection: Integrated
- Anti -islanding Protection: Integrated
- PV String Input Reverse Polarity Protection: Integrated
- Insulation Resistor Detection: Integrated
- Residual Current Monitoring Unit: Integrated
- Output over Current Protection: Integrated
- Output Shorted Protection: Integrated
- Output over Voltage Protection: Integrated

Certifications and Standards
- Grid Regulation: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
- Safety Regulation: IEC62109-1, IEC62109-2
- EMC: EN61000-6-1, EN61000-6-3, FCC 15 class B

General Data
- Operating Temperature Range ( C ): -25—60 C , >45 C Derating
- Cooling: Fan
- Noise (dB): <30
- Communication with BMS: RS485; CAN
- Weight (kg): 20.5
- Size (mm): 580 X 330 X 208mm
- Protection Degree: IP65
- Installation Style: Wall-mounted
